Key Specifications

• Technology: Vortex flow measurement

• Mediums: Liquids, gases, steam

• Nominal Size: 2" (per nameplate)

• Max Flow (Gas): ~9,711 m³/h

• Max Pressure (PS): 19 bar

• Pressure Test: 29 bar

• Process Temperature: up to ~185°F (85°C)

• Ambient Temperature: –40 to +185°F

• Power Supply:

  • 11–35 VDC (4-wire)

  • 85–250 VAC (depending on configuration)

• Output / Communication:

  • 4–20 mA HART

• Enclosure Rating: IP66 / IP67

• Hazardous Area Approvals:

  • Class I, Div 1 / Zone 1 (Ex-rated)

• Materials:

  • Wetted parts: Stainless steel (1.4404 / 316L equivalent)

  • Gasket: Graphite

• Certifications: CE, CSA, FM

Accepted Payment Methods: Cash or Certified Check.
All funds must clear prior to release of equipment.

Delivery -  All equipment is sold FOB our facility. Buyer assumes responsibility for freight, insurance, and risk of loss once the item leaves our dock.
