Electrical Specifications

• Horsepower: 7.5 HP

• Voltage: 208-230 / 460 V

• Amps: 18.6 – 17.2 / 8.9 A

• Phase: 3 Phase

• Frequency: 60 Hz

• RPM: 3525 RPM

• Service Factor: 1.15

• Design: A

• Code: K

• Insulation Class: F

Mechanical Specifications

• Frame Size: 213TC

• Enclosure: TEFC (Totally Enclosed Fan Cooled)

• Ambient Rating: 40°C

• Duty Rating: Continuous

Efficiency

• NEMA Nominal Efficiency: 91%

• Power Factor: 90%

Bearings

• Drive End Bearing: 6309

• Opposite Drive End Bearing: 6206
